FTVOGUE Function Signal Generator 0.01Hz500KHz Frequency Counter Waveform Source Module Electronic Signal Testing Module Sine Square and Sawtooth Wave

Specification: Item Type: Function Signal Generator Material: ABS Size: Approx. 140 x 80 x 26mm / 5.51 x 3.15 x 1.02in Main Technical Parameters: Output Waveforms: Sine Wave, Square Wave, Triangle​​​ Wave, Positive Sawtooth Wave, Negative Sawtooth Wave, Electrocardiogram Wave, Exponential Rise, Exponential Fall, Gaussian Pulse, Sinc Pulse, Half Wave, Full Wave, Noise Wave Power Supply: DC4-9V (Recommend Using DC5V Adapter when using adapter, or 3.7V Lithium Battery when using battery power(battery not included)) Current: 180MA at 5V Frequency Range: Sine Wave 0.01Hz-500.00kHz, Other Waveforms 0.01Hz-100.00kHz Resolution: 0.01Hz Sine Wave Distortion: Output Amplitude: Maximum ±10V (P-P) Output Impedance: 50 ohm DC Offset: Maximum ±10V Can save all set parameters. Comes with a filter that can be turned on and off to adapt to sine and pulse waveform output. How to Use: Direct installation and use. Packing List: 1 x Function Signal Generator 1 x USB Power Cable 1 x BNC Coaxial Cable 1 x Dual End BNC Cable 1 x Antenna

• [Multifunctional] This signal source generator meter is multifunctional and can test a variety of forms, such as sine wave, square wave, triangle wave, forward sawtooth wave, reverse sawtooth wave, and so on.
• [Compact and Lightweight] This DDS functional signal generator is small in size and lightweight, which makes it very convenient to carry and use, and it can be powered by a power adapter or a 3.7V lithium battery(battery not included).
• [Good performance] This signal source module has good accuracy and frequency stability, it is also well suited for oscilloscope sweep time factor calibration. Sine waveform 0.01Hz‑500.00kHz (output amplitude decreases with further increase in frequency), other waveforms 0.01Hz‑100.00kHz .
• [Wide Application] This DDS signal generator is used in conjunction with an oscilloscope for electronic circuit testing and debugging, frequency characteristics of sound amplifiers and impulse response testing and measurements. There is a filter (which can be turned on and off) to accommodate sine and pulse outputs.
• [Excellent ABS Material] This function signal generator frequency module is made of excellent ABS material, which is sturdy , not easy to be damaged, and has a long service life.
